Referenser
Dormer:EX205/16
Rubix:6188216
EAN:7320760150337
Produktinformation : GÄNGTAPP 5/16 inchx18 HSS-E BLANK DIN 2184-1 - EX205/16 - DORMER
HSS-E Machine thread-cutter for UNC thread uncoated DIN 2184-1 shape C 45° spiralised 2.5xD blind holes for steel <1200 N/mm². Copper. Brass en bronze <200 HB. Aluminium and aluminium-magnesium alloys.
Användningsområden
• Machining steel soft steel (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• Alloy steel hardened and tempered steel (>250<350 HB >850<1200 N/mm²)
• aluminium magnesium non-alloyed (<100 HB <350 N/mm²)
• aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Aluminium alloyed Silicon > 0.5% <10% (<120 HB <400 N/mm²)
• Aluminium alloyed Silicon >10% whisker reinforced Aluminium-alloys Magnesium-alloys (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• Alloy steel hardened and tempered steel (>250<350 HB >850<1200 N/mm²)
• aluminium magnesium non-alloyed (<100 HB <350 N/mm²)
• aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Aluminium alloyed Silicon > 0.5% <10% (<120 HB <400 N/mm²)
• Aluminium alloyed Silicon >10% whisker reinforced Aluminium-alloys Magnesium-alloys (<120 HB <400 N/mm²)
Teknisk information
Attribut
| Typ | amerikanska genomgående hål |
|---|---|
| Med kylspray | nej |
| Borrdiameter | 6.6 mm |
| Fyrkantsadapter | 8 mm |
| Helix vinkel | 45 ° |
| Beläggning | blank |
| Total längd | 90 mm |
| Material | hss-e |
Att visa UNSPSC/ECL@SS/Customs
622,21 kr Ex moms
/ Styck
777,76 kr Inkl moms
- Tillgänglig – Leveransdatum på begäran
