Referenser
Dormer:S9022.0
Rubix:6189494
EAN:7320760132753
Produktinformation : Pinnfräsar, S9022.0 - 5983010 - DORMER
VHM Short key-way cutter with DIN 6535 HA shaft N 30° uncoated 2-cutter for steel <850 N/mm². Cast iron. Titanium and nickel. Copper and alloys of copper.
FRAISE 2.00 2D NORMAL S902 30DEG CW MICROGAIN
Användningsområden
• Machining steel soft steel (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Titanium non-alloyed (<200 HB <700 N/mm²)
• nickel non-alloyed (<200 HB <700 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Titanium non-alloyed (<200 HB <700 N/mm²)
• nickel non-alloyed (<200 HB <700 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Béta-Brass Bronze (<200 HB <700 N/mm²)
• Alfa-Brass (<200 HB <700 N/mm²)
Teknisk information
Attribut
| Diameter | 2 mm |
|---|---|
| Typ av fäste | ha |
| Diameter fäste | 3 mm |
| Antal tänder | 2 |
| Klipplängd | 6 mm |
| Total längd | 38 mm |
| Mittskär | centered cutting (centre cutting) |
| Skärmaterial | karbid |
| Beläggning | bright finish |
| Typ | vhm finger cutter/end mill (s902, mc-x) |
| Helix vinkel | 12 ° |
| Bearbetning av material | steel, cast iron, titanium, nickel and copper and copper alloys |
| Skärvinkel | 30 ° |
Att visa UNSPSC/ECL@SS/Customs
319,04 kr Ex moms
/ Styck
398,80 kr Inkl moms
- Tillgänglig – Leveransdatum på begäran
